PrimePro Marine Power Control Cable SWA Armoured | Class 2/5 Tinned Copper | IEC 60092 | LSHF Flame Retardant | IP67/IP68 | TCWB

Product Specifications

• Oil Resistance: High Resistance as per IEC 60811-404 (Standard for Offshore)
• Mud Resistance: Optional compliance with NEK 606 (Oil & Mud Resistant)
• Smoke Density: Low Smoke Emission as per IEC 61034-1, 2
• Halogen Content: Zero Halogen as per IEC 60754-1, 2
• Min. Bending Radius: 6x - 10x Overall Diameter (Installation Friendly)
• Corrosion Resistance: Salt-Spray Tested (ISO 9227) for Marine Environments
• UV Resistance: 720h Tested as per ASTM G154 (Anti-Aging)
• Tensile Strength: ≥ 12.5 MPa (Jacket Material Strength)
• Dielectric Strength: 3.5kV / 5min (No Breakdown)
• Delivery Lead Time: 7-15 Working Days (Expedited Global Shipping)
• Place of Origin: CN;BEI
• Conductor Material: High-Purity Tinned Annealed Copper
• Insulation Material: XLPE / EPR
• Jacket: LSHF / PO / SHF1
• Working Temperature: -40°C to +90°C
• Model Number: PR-MAR-SWA-2026
• Brand Name: PrimePro
• Application: Offshore Platforms, Shipboard, Oil & Gas Infrastru
• IP Level: IP67 / IP68 (Water-tight Construction)
• Size: 1.5mm² to 300mm² / Multicore
• Shielding: Tinned Copper Wire Braid (TCWB) / Aluminum Foil +
• Flex Life: 5,000,000 - 10,000,000 Cycles (Class 5 Conductor V
• Impedance: 75Ω / 100Ω / 120Ω (Customizable for Control/Signal
