Heavy Duty H07RN-F Rubber Cable Flexible EPR Insulation Neoprene Jacket UV Resistant Flame Retardant Weather Resistant Power

Product Specifications

• Oil Resistance: EN 60811-404 (Excellent resistance to industrial oils and fats)
• UV Resistance: High-grade UV-stable jacket for permanent outdoor installation
• Torsion Angle: ±90°/m (Suitable for torsional stress in industrial applications)
• Min Bend Radius: Fixed: 4-6 x OD; Mobile: 6-8 x OD (Optimal flexibility)
• Ozone Resistance: Fully resistant to ozone cracking per EN 50396
• Water Resistance: AD8 rating (Submersible up to 10 meters depth)
• Mechanical Grade: High resistance to impact, abrasion, tearing, and crushing
• Chemical Profile: Resistant to acids, alkalis, and common industrial solvents
• Certifications: KEMA-KEUR, CE, RoHS, REACH, CPR Eca compliant
• Conductor Resistance: Max DC resistance at 20°C per EN 60228 Class 5 requirements
• Place of Origin: CN;BEI
• Conductor Material: Class 5 flexible plain copper
• Insulation Material: High-grade EPR Type EI4
• Rated Voltage: Rated 450/750V (Test Voltage: 2500V; Max 0.6/1kV f
• Size: H07RN-F
• Model Number: H07RN-F (Standard European Heavy-Duty Rubber Cable
• Brand Name: PrimePro
• Application: Industrial power, tools, submersible pumps, cranes
• IP Level: IP68 (Certified for permanent water immersion AD8)
• Jacket: Polychloroprene Type EM2, Oil & Abrasion Resistant
• Rated Current: Optimized current carrying capacity per IEC 60364-
• Type: Flexible Heavy-Duty Chloroprene Sheathed Cable
• Working Temperature: Mobile: -30°C to +60°C; Fixed: -35°C to +85°C; Max
• Flame Retardant Class: IEC 60332-1-2 (Flame retardant and self-extinguish
